Length
100m
Core
A4 steel
Tightness class
IP67
DSP
Hi3516D
Sensor
OV4689
Video resolution
5MP@15fps 4MP@18fps 3MP@30fps
Min. illumination (color)
0.0051Lux (color) 0Lux (IR)
Shutter
1/2s-1/1000s
Audio in/out
yes
Lens
2.7 - 13.5 mm
IR Distance
up to 60m
Local storage
Micro SD / USB
Digital noise reduction
3D digital noise reduction
WDS
digital WDR
ROI
yes
Defog
yes
Codec (video)
H.264 / H.265 / MJPEG
Codec (audio)
AAC, G.711
PoE
yes
Materials
metal housing
Color
black & white
Accessories
installation kit
Power supply
12V DC / PoE
Operating temperature
-40 to +60 C deg
Waterproof
IP67
Vandalproof
IK10
Size
289.7x94x85.7 mm
Weight
brutto: 1300g, netto: 1200g
Impedance
50 Ohm
Operating frequency
up to 6 GHz
Technical specification
Model
BP-26PL-18-MIMO
Gain
18
dBi
Operating frequency
2500 - 2690
MHz
Vertical beam width
13 deg
Horizontal beam width
13 deg
Impedance
50 Ohm
Connector
2 x N type socket
(female)
VSWR
1.37
Radiating element
DC short circuit
Dimensions
510 / 510 / 38.1
mm
Weight
3.47 kg
Polarization
vertical/horizontal (both)
Standards
LTE MIMO fully compatible
Mounting
Mast handle, diameter from 1/2 to 7/4 inch (allows full rotation and azimuth correction).
Wind load
frontal: 455 N (at 125 mph)
rearside: 416 N (at 125 mph)
lateral: 21 N (at 125 mph)
Technical specification
Model
BP-26PL-15-MIMO
Gain
15
dBi
Operating frequency
2500 - 2690 MHz
Vertical beam width
30 deg
Horizontal beam width
32 deg
Impedance
50 Ohm
Connector
2 x N type socket (female)
VSWR
1.4
Radiating element
DC short circuit
Dimensions
304.8 / 304.8
/ 38.1 mm
Weight
2.27 kg
Polarization
vertical/horizontal (both)
Standards
LTE MIMO fully compatible
Mounting
Mast handle, diameter from 1/2 to 7/4 inch (allows full rotation and azimuth correction).
Wind load
frontal: 163 N (at 125 mph)
rearside: 148 N (at 125 mph)
lateral: 13 N (at 125 mph)
UPS inverter single phase line-interactive PST1.5K 1500W 24V
Pure sine wave output
Bult in PWM - PV loading controller
Construction of an insulating transformer for difficult electrical conditions and the protection against electric shock
Selectable input voltage
Selectable charging current depending on connected equipment
Configurable input from solar modules via LCD interface
Compatible with mains voltage or generator
Auto restart after return of mains power
Short-circuit and overload protection
Smart battery charging (significantly extends battery life)
Cold start function
Maximum charging current 25 A from the mains, 20 A from the photovoltaic (solar)
Excellent microprocessor control guarantees high reliability
UPS inverter single phase line-interactive AV0K5 300W 12V
Full digital control of the design concept, application of intelligent CPU control System, combined with CMOS and PWM, built in power Intelligent charger.
On battery it generates pure sine wave .
Upon power failure or significant low voltage, the UPS will provide power until the battery voltage drops significantly, after which the UPS will shut down. When the mains power is restored, the UPS automatically turns on and starts charging the battery and power supply. No need to manually turn on the UPS.
